      M2141(OPS)



      Detailed






      The product meets the standard OPS-C design specifications







Intel 11th Tiger Lake U Platform







Supports HDMI1.4+DP1.4+HDMI2.0 display output







Supports HDMI2.0 OPS interface with maximum support 4K@60Hz display







Supports 3 * USB3.0+3 * USB2.0+1 * Type-C USB3.0







Supports DDR4 dual channel memory 3200MHz Max32G







Support Key M NGFF M.2 interface, expandable SSD module







Support Key E NGFF M.2 interface, expandable WiFi+Bluetooth







Support hardware one click system backup and restore







Enhanced USB signal driving capability, compatible with various touch boxes and other devices






































CPU
Supports Intel 11th Tiger Lake U platform processors
IO terminal display
Intel ®  Iris Xe Graphics
      HDMI1.4: Up to display resolution 4096x2304@30Hz DP1.4: Up to display resolution 7680x4320@60Hz




Chipset
SoC




BIOS
BIOS AMI 128Mbit, supporting functions such as write protection, diskless startup, wake-on-LAN, power on startup, timed startup, watchdog remote switch on/off device intelligent recognition, etc




Memory
2xSO-DIMM，DDR4 3200MHz Max32GB




Storage
1 x SATA interface  (for 2.5“Hard disk )SATA3.0




1 x M.2 Key M interface (NVMe), interface M.2 2280mm SATA &PCIe SSD
I/O interface
USB 3 x USB3.0 3 x USB2.0
      LAN :1 x Type-C USB3.0；1 x RJ45
      Socket 1 x DC power socket 1 x OPS80pin
      LED 1 x POWER LED    1 x HDD LED
      Button  :1 x Power Button
      1 x RESET (short press to restart and long press CLR-CMOS)
      1 x Ghost key (system one click restore)




OPS display
HDMI2.0: Up to display resolution 4096x2304@60Hz




Network
Wired 1 x RTL8111H 10/100/1000M (onboard RJ45)




Wireless  1 x M.2 Key E(For WIFI+Bluetooth module)




Audio frequency
1 x LINE-OUT &1 x MIC-IN




Power
DC 12~19V




Watchdog
Functional downtime and system restart




Interval 1~65535sec




Operating system
windows10 / Linux




AC  adapter
AC:100-240V 60/50HZ




power supply
INPUT : 100-240V  1.5A 50/60 Hz




Output : 12.0v-7.0A




Power :90W




Environment
Working temperature: -10~60 ℃; 0%~95% relative humidity, non condensing




Size
180 (L) x 195 (W) x 42(H)mm
